6252Z | Water dispenser for Sauna, 24/48 V, Bluetooth

Oras Electra

EAN code
6414150101083
Active markets
FIN

Bluetooth Water dispenser for Sauna
Adjust settings from Bluetooth app
Max Flow time
Pause time

Find local retailer
Features
  • Additional features Flush delay: 1 s
  • Connection One inlet for cold or premixed water, External thread
  • Electronic parts Solenoid valve
  • Extensions Mechanical push button
  • Advanced features Software settings adjustable via App
Software settings
  • Max. flow period 4 s (0.5 - 8 s)
Flow attributes
  • Flow-rate at 300 kPa (with flow controller) 0.1 l/s
  • Pressure loss with flow (0.1 l/s) 200 kPa
Technical properties
  • Hot water supply max. +70°C
  • Working pressure 100 - 1000 kPa
Electronics
  • Bluetooth version 5.x (D060577)
  • Connection cable 5 m
  • Electrical Connection 24-48V
Regulations
  • EU Directives Radio Equipment Directive 2014/53/EU , Low Voltage Directive 2014/35/EU , EMC Directive 2014/30/EU , RoHS Directive 2011/65/EU
  • EN standard EN 15091, ETSI EN 301 489-1 V1.9.2 , ETSI EN 300 328 v2.2.2 , EN 61000-6-1:2007 , EN 61000-6-3:2007+A1:2011+AC:2012 , EN 60335-1:2012+A11+A13+A1+A14+A2+A15:2021, Part 19.11.4
  • Noise class I (ISO 3822)
  • Protection class IP 67

SP6252Z Water dispenser for Sauna

Ask pricing from your local retailers.

Spare parts Code Spare part guide
01
Circuit card
Circuit card
  • 1015602V
Download
02
Solenoid valve, 12/24/48 V
Solenoid valve, 12/24/48 V
  • 1014683V
Download
03
Operating switch, 5 m
Operating switch, 5 m
  • 600408V
Oras Group, Transformer, 24 V, 290004
Oras Group
Transformer, 24 V
290004
Oras Group, Power supply, 24 V, 290005
Oras Group
Power supply, 24 V
290005
Oras Group, Transformer, 24 V, 290004
Oras Group
Transformer, 24 V
290004
Oras Group, Power supply, 24 V, 290005
Oras Group
Power supply, 24 V
290005
